Specification

Drive Mode

AC VFD

Rated Drilling Depth

5000m (114mm drill pipe)

Rated Load Capacities

3150 KN

350 ton

Power Supply

600 VAC/ 50Hz

Rated Current

465A

Max. Current

700A

Rated Power(continuous)

375kw

500HP

Rotary Speed

0-180 r/min

Drilling Torque (continuous)

40 KN·m

29500 lb·ft

Max. Torque of Break Out

60 KN·m

44250 lb·ft

Backup Tong Range

87～216mm

3-1/2～8-1/2 in

Hydraulic System Working Pressure

16MPa

2280 psi

Rated Pressure of IBOP

70MPa

10000 psi

Mud Circulating Diameter

75 mm

3 in

Rated Circulating Pressure

35MPa

5000 psi

Max. distance between Main Shaft Center and The Front End

705 mm

27.7 in

Main Body Height

5 m

16.39 ft

Ambient Temperature

-35～55℃
