model

FXD

QF2

Q3

Max.static load

kn

2250

2250

2250

Us ton

250

250

250

Air pressure

mpa

0.5-0.9

0.5-0.9

0.5-0.9

psi

72-130

72-130

72-130

Rated torque

n.m

1196

1600

1650

Ft.lbf

882

1180

1217

Breaking torque

n.m

1500

2500

2500

Ft.lbf

1100

1844

1844

Rated speed

rpm

76

72

72

Spinning direction

single direction

double direction

double direction

Stem connection thread

6 5/8REGLH

6 5/8REGLH

6 5/8REGLH

Overall dimensions

mm

845*740*725

558*558*935

860*725*980

in

33*29*28

22*22*27

34*28*39

weight

kg

383

450

520

lb

844

992

1146
